Continuous-Duty Electric Lubrication Pump with Magnetic Return Filtration

continously-workable-lubrication-grease-pump-ga-roc

Features

Equipped with a return port and a return filter.
Fluid Level & Pressure Alarms
High-Performance Motor with Cooling Fan
Innovative Magnetic Return Filtration
Safety Relief Valve
Anti-Vibration High-Strength Metal Tank
Precise Volumetric Compatibility

Overview

The GA Series Electric Gear Lubrication Pump is a high-performance lubrication solution designed for medium and small-sized machinery requiring continuous operation. It is suitable for thin oils and soft greases ranging from NLGI 00# to 000#. Featuring wear-resistant metal gears, the pump offers stable output and reliable long-term service.

Compact in design and equipped with an integrated pressure relief valve, it protects the lubrication system from overloads. The GA pump supports flexible mounting options and can be controlled via built-in timers or external PLC signals, enabling intelligent and efficient lubrication management.

Specifications

型号 Model	GA-ROC-520*	GA-ROC-523*
容量 Reservoir capacity	6L/10L/20L	6L/10L/20L
控制方式 Control type	PLC	TIMER
用脂范围 Lubricant	Oil/00-000#	Oil/00-000#
电压 Voltage	220V/380V	220V/380V
功率 Power	60W	60W
最高工作压力 Max.pressure	4.0Mpa	4.0Mpa
流量 Discharge volume	300CC/Min	300CC/Min
回油过滤装置 Returned oil filter	✓	✓
脱压装置 Pressure relief valve	✓	✓
压力表 Pressure gauge	✓	✓
吐出口径 Outlet thread	6mm (default)	6mm (default)
压力报警 Pressure switch	选配 Optional	选配 Optional
液位报警 Level switch	选配 Optional	选配 Optional
